Porkka Cold Line Counters for Food Storage and Preparation

Porkka cold line CL-GNH counters are designed to be used as both preparation work tables and food storage units Porkka counters are designed for use in busy kitchens in restaurants, food preparation areas, café’s, canteens etc.

Counters are manufactured from quality components they are durable and long lasting, naturally, the counters are supplied ready for the usage and benefit from stainless steel AISI grade 304 bodies both internally and externally.

Pre-configure your counter

There are multiple variations of CL-GNH –models. You can design your counter with the web application (requires Adobe Flash). To see more information on available variations, please check the tab “available modules”.

COUNTER CONFIGURATOR (Flash)



Didn’t find what You are looking for?

Do you want special configuration to fulfill your needs? Please, go to contact center page and send an e-mail to your local specialist.

CONTACT CENTER >
SKU: CL-GNH Categories: , ,

Description

Each door or drawer is fitted with handle and easy to change pull out / push in gaskets and the base is supplied with height adjustable legs or castors. Shelving is included with each door section and drawers can also be supplied with internal base.

The equipment also benefits from innovative design features such as pull out refrigeration cassettes for simple maintenance or repair. Each door or drawer section can accept GN1/1 trays or pans or multiples of smaller sizes to suit the application.

Features

  • Environmental friendly and energy efficient refrigerant R290
  • Digital temperature display with built-in microprocessor controller
  • Recording of max./min. temperature
  • Visual high/low temperature alarm
  • Probe failure alarm
  • Blocked condenser / high ambient temperature alarm
  • Exterior / Interior finish in stainless steel
  • Insulation with high density HFC-free polyurethane
  • 2 pcs GN 1/1 dimensioned, powder coated, steel wire shelf,
  • adjustable in increments of 70 mm (per door section)
  • Door equipped with magnetic gasket and heavy-duty hinges
  • Efficient and energy saving, hermetic air cooled HFC- free
  • refrigerant system
  • Slid-in/out refrigeration cassette (by hand) for easy servicing
  • Built-in washable condenser air filter
  • Stainless steel legs, height adjustable (-5mm to +65 mm)
  • Electrical supply 230V/50Hz

Optional Features

  • Medium temperature (-5°…+5°C) and freezer (-25°…-15°C models available for counters with a width of 860,1260 & 1660 mm (2060 mm available only +2°…+15°C)
  • Also available for connection to a central cooling refrigeration system (chiller models only)
  • Module with 1, 2, 3 or 4 drawers with handle and magnetic gasket • Extra shelves as required
  • Shorter, adjustable stainless steel legs for a counter height of 825 mm
  • Special size table tops
  • Heat treated wooden packaging

Features available for chiller (C) models only:

  • Connection to a central cooling refrigeration system
  • Module with 2, 3 or 4 drawers with handle and magnetic gasket
  • Module refrigeration cassette with 1 drawer incl. handle (CD),
    magnetic gaske (width 860, 1260 & 1660 mm only)

Technical Specification

Cold line R290* CL-GNH C860 CL-GNH C1260 CL-GNH C1660 CL-GNH C2060
Energy efficiency class C C,D* D D
Energy efficiency index 40,1-46* 44,8-53,1* 48,6-59,4* 51,6-63,1*
Energy Consumption (kWh/Year) 828/935* 1050/1157* 1271/1378* 1493
Net Volume EN16825 (litres) 56,6-146,3* 113,1-254,3* 169,7-362,3* 226,2-432*
Climate class 4 4 4 4
Operating Temperature +2…+15 °C +2…+15 °C +2…+15 °C +2…+15 °C
Amb. Temperature +5…+25 °C +5…+25 °C +5…+25 °C +5…+25 °C
Width (mm) 860 1260 1660 2060
Depth (mm) 650 650 650 650
Height (mm) 900 900 900 900
Height with short legs (mm) 850 850 850 850
Gross weight (kg) 87 114 144 180
Connection power (kw) 0.25 0.25 0.25 0.35
Voltage 230V/50Hz 230V/50Hz 230V/50Hz 230V/50Hz
Defrost Air Air Air Air
Refrigerant (g)/GWP R290/90 g (GWP 3) R290/90 g (GWP 3) R290/90 g (GWP 3) R290/130 g (GWP 3)


* Value depending on a configuration|Available modules

Available Modules

Module 1 Module with door Solid door with 2 shelves
Module 2 Module with 2 drawers 2 drawers with telescopic rails for GN-containers (200 mm deep)
Module 3 Module with 3 drawers 3 drawers with telescopic rails for GN-containers (150 mm deep)
Module 4 Module with 4 drawers 4 drawers with telescopic rails for GN-containers (3 x 100 mm and 1 x 150 mm deep)
Module M* Refrigeration unit M without drawer -5…+5 °C
Module F* Refrigeration unit F without drawer -25…-15 °C
Module CE* Refrigeration unit CHE without drawer with Eco refrigerant R290 +2…+15 °C
Module CDE* Refrigeration unit CDE with a drawer with Eco refrigerant R290 +2…+15 °C
Module CHE Refrigeration unit CHE without drawer with Eco refrigerant R290  +2…+15 °C
* not available in 2060 mm width counter

Brochures

 Porkka Counters (PDF)
